AINiCo Magnet

Product Description

AlNiCo permanent magnets can be classified into cast AlNiCo and sintered AlNiCo based on the manufacturing process. Both types offer good corrosion resistance, so surface coating is generally not required. AlNiCo magnets can be produced in various shapes and sizes according to customer requirements. With a maximum operating temperature exceeding 400°C, they feature excellent magnetic stability and high-temperature resistance, making them widely used in industrial equipment, instruments, and magnetic devices.

Assemblies

Assemblies are available based on specific project requirements. Customized magnetic assemblies can be designed and manufactured to meet different application needs.

Technical Overview

Grades	Equivalent MMPA Class	Remanence Br		Coercive Force Hcb		Maximum Energy Product (BH)max		Density	Reversible Temp. Coefficient а(Br)	Reversible Temp. Coefficient а(Hc)	Curie Temp. TC	Temp.Coefficient TW
		Remanence Br		Coercive Force Hcb		Maximum Energy Product (BH)max		Density	Reversible Temp. Coefficient а(Br)	Reversible Temp. Coefficient а(Hc)	Curie Temp. TC	Temp.Coefficient TW	mT	Gs	KA/m	Oe	KJ/m3	MGOe	g/cm3	%/℃	%/℃	℃	℃
		LN10	ALNICO3	600	6000	40	500	10	1.2	6.9	-0.03	-0.02	810	450
LNG13	ALNICO2	700	7000	48	600	12.8	1.6	7.2	-0.03	0.02	810	450
LNGT18	ALNICO8	580	5800	100	1250	18	2.2	7.3	-0.025	0.02	860	550
LNG37	ALNICO5	1200	12000	48	600	37	4.65	7.3	-0.02	0.02	850	525
LNG40		1250	12500	48	600	40	5	7.3
LNG44		1250	12500	52	650	44	5.5	7.3
LNG52	ALNICO5DG	1300	13000	56	700	52	6.5	7.3	-0.02	0.02	850	525
LNG60	ALNICO5-7	1350	13500	59	740	60	7., 5	7.3	-0.02	0.02	850	525
LNGT28	ALNICO6	1000	10000	57.6	720	28	3.5	7.3	-0.02	0.03	850	525
LNGT36J	ALNICO8HC	700	7000	140	1750	36	4.5	7.3	-0.025	0.02	860	550
LNGT38	ALNICO8	800	8000	110	1380	38	4.75	7.3	-0.025	0.02	860	550
LNGT40	ALNICO8	820	8200	110	1380	40	5	7.3	-0.025	0.02	860	550
LNGT60	ALNICO9	950	9500	110	1380	60	7.5	7.3	-0.025	0.02	860	550
LNGT72	ALNICO9	1050	10500	112	1400	72	9	7.3	-0.025	0.02	860	550

AlNiCo is a hard magnetic material primarily composed of aluminum, nickel, and cobalt, combined with metals such as copper and iron. It features high remanence, low temperature coefficient, and excellent magnetic stability, and is widely used in instruments, permanent magnet motors, sensors, and related applications.
